Monitoring
All signals presented to the patient can be monitored by the examiner via a
monitoring headset or the speakers integrated in the device. For this purpose,
press the monitor button (6) and the monitor screen will appear. The monitor
level of the left and right channel can be adjusted with the corresponding
level control dial (1). The integrated speaker is switched on by pressing the
button (13) and the external headset via the functional selector button (11). In
order to hear the signal given to the patient, make sure to activate the
corresponding channel for monitoring (buttons 9 and 17).
The talk back microphone is activated by the button (15) and its level adjusted
by the frequency up and down buttons (4), (5).
Talk Forward
Connect the microphone headset to the microphone socket (8) on the rear
side of the device. A gooseneck microphone can also be connected.
Note: Only connect the microphone when the unit is off.
To talk to the patient press and hold the Stim/Talk button (8) and speak into
the microphone. Pressing only one Stim /Talk button is required to activate
this feature. Adjust the level by the left or right level control (1) while holding
down the Stim /Talk button.
Documentation of the Results
All stored results can be directly printed by a USB printer. Make sure that a
compatible printer is connected to the USB port (4) and the device is correctly
configured to the connected printer (refer to Menu Settings chapter 7.2).
The results can also be stored as PDF file on an SD memory card or USB flash
drive to be transferred to a PC for further usage. The PDF file contains all the
