Operation Manual touchTymp MI 26 and MI 36 Version
8511780 Rev. 4
52
30/06/2021
ICON
FUNCTION
EXPLANATION
Home
Home (only for Audiometry test screen): to return to the
Home screen for test selection.
Setting
screen
Default
Default: to set the device back to factory settings.
Save
Save: to save current selection.
NOTE: An active button is displayed in blue.
Audiometry Main Screen Display (Versions MI 26 with Bone Conduction and MI 36)
Figure 86
For explanation of the Audiometry Main Screen Display (Versions MI 26 with Bone
Conduction and MI 36) see Table 13.
4
9
1
2
3
5
6
7
8
10
11
12
13
13
