6
RangeBasic Functions
3. General Specifications
Clamp jaw opening 28mm approx.
Display 2000 Count (2-1/2 digits backlit LCD)
Low Battery indication is displayed
Over-range indication 'OL' display
Measurement rate 3 readings per second, nominal
Input Impedance 10M (VDC and VAC)
AC response Average Reading (AAC and VAC)
ACV Bandwidth 2KHZ
Operating Temperature 5°C to 40°C (41°F to 104°F)
Storage Temperature -20°C to 60°C (-4°F to 140°F)
Operating Humidity Max 80% up to 31°C (87°F) Decreasing
linearly to 50% at 40°C (104°F)
Storage Humidity <80%
Operating Altitude 2000meters (7000ft.) maximum.
Battery 2 x 1.5V AAA Battery
Battery life Approx. 30h (backlight ON), Approx.
100h (backlight OFF)
Auto power OFF After approx. 15 minutes
Dimensions 185 x 65 x 37mm
Weight 180g
Safety For indoor use and in the requirement
For double insulation IEC1010-1(2001):
EN61010-2-030, EN61010-2-032,
EN61010-2-033 Over voltage Category
III 600V, Pollution Degree 2.
4. Specifications
2.000A 1mA ±3.0% of rdg±5 digits
20.00A 10mA
200.0A 100mA ±2.0% of rdg±5 digits
600A 1A
Range Resolution
4.1. AC True RMS Current
Accuracy (% of reading + digits)
Over range protection: Maximum input 600A
Accuracy specified from 5% to 100% of the measuring range
Frequency Response: 50Hz to 60Hz True RMS
