MAKELSAN Lion+ Series - Page 19

UDD-SD-110/ Release Date: 19.12.2014/Rev No: 1/Rev. Date: 30.07.2015
CAPACITY
650VA/390W
850VA/510W
1000VA/600W
1500VA/900W
2000VA/1200W
INPUT
RATED VOLTAGE
220/230/240VAC
VOLTAGE RANGE
162VAC-268VAC±%7
FREQUENCY RANGE
50/60Hz ±%1
OUTPUT
RATED VOLTAGE
220/230/240VAC
VOLTAGE PRECISION
±%10 (Battery mode)
FREQUANCY (AC
MODE)
same as mains
FREQUANCY
(BATTERY MODE)
50/60Hz ±%1Hz
WAVEFORM
Modified sine wave
CREST FACTOR
3:1
TRANSFER TIME
2 ~ 6 ms, 10 ms Max.
4 ~ 8 ms, 10 ms Max.
OVERLOAD
line mode:
110%+20%/-10%; shutdown after 5 minutes and go to fault mode for all model.
120%+20%/-10%; shutdown immediately and go to fault mode for 1B model
120%+20%/-10%; shutdown after 8 sec and go to fault mode for 2B model
battery mode:
110%+20%/-10%; shutdown after 5 seconds
120%+20%/-10%; shutdown immediately
EFFICIENCY
INVERTER MODE
line mode: >95%
AVR mode: >88%
BATTERY MODE
>60%
BATTERY
BATTERY
CONFIGURATION
12V/7AH*1
12V/9AH*1
12V/7AH*2
12V/9AH*2
12V/9AH*2
CHARGE CURRENT
About 1A at normal mode
RECHARGE/CHARGING
TIME
6 hours to 90% at normal mode after complete discharge (Load>50%)
BACKUP TIME
~ 16 min.
~ 20 min.
~30 min.
~ 50 min.
~ 50 min.
PROTECTION
FULL PROTECTION
Discharge, overcharge, overload
protection
Discharge, overcharge, overload, short circut
protection
INDICATION
AC MODE
Green LED lighting
Green LED lighting
BATTERY MODE
Green LED lighting
Yellow LED lighting
FAULT
N/A
Red LED lighting
ALARM
BATTERY MODE
Sounding every 10 seconds
BATTERY LOW
Sounding every 1 seconds
OVERLOAD
Sounding every 0.5 seconds
FAULT
Continuously sounding
PHYSICAL
DIMENSION (W*D*H)
278*100*143 mm
365*139*195 mm (for 1B and 2B model)
PACKİNG (W*D*H)
332*142*225 mm
457 * 235 * 297 mm
