＞Turn off the parallel system
Hold on the OFF KEY of any one UPS of system for more than 4 seconds, it would turn off the
whole parallel system. Hold on the OFF KEY of any one UPS of system for more than 1
second(less than 4 seconds), it would turn off single UPS you choose, of course if you need to
turn on it again or turn on any other single UPS of the system, just press ON KEY of that UPS to
start it.
＞Parallel system maintenance
 Parallel system maintenance please follow the maintenance of single UPS.
 If one UPS of parallel system is malfunctioning, first of all, turn off the malfunctioning UPS, then
cut off the input power to the faulty UPS and disconnect the output of faulty UPS to the parallel
system, make sure that there is no electrical connection with malfunctioning UPS, after all of
those, it’s safe to do operation.
3.4 External Battery Connection Procedure for Long Back up Type
 For different UPS type, users are instructed to configure different battery voltage as below
sheet. More or less units are forbidden, or else something abnormal or faulty will appear.
Type
Battery Quantity
(unit)
Battery Voltage
(volt)
6KVA 16/20 192V/240V
10KVA 16/20 192V/240V
15KVA 16/20 192V/240V
20KVA 16/20 192V/240V
NOTE
There are two battery pack options for UPS, 16 units and 20 units. Users can choose the
different battery pack voltage in accordance with different requirements. The default units of
batteries to UPS is 16, and users can not connect 16 batteries to UPS if the UPS should be
connected 20 units. Please strictly follow the procedure of batteries connection, or will get
electric shocks.
1. Set the battery switch at ‘OFF’ position, then install batteries in series.
2. Connecting the cables to batteries firstly, or you may get electric shocks if you connect the
cables to UPS firstly. You’d better connect the red cable to battery positive pole ‘+’, black to
negative pole ‘-’, so that it would be much easier to distinguish.
3. Select proper cables to connect the batteries and UPS is very important, and there should be a
switch connected between the battery pack and UPS.
4. Finally, without any load, set on the battery switch which is connected between the UPS and
the battery pack, so that UPS can get connected to batteries, then switch in the mains power,
after doing all of those, the batteries will be charged by the UPS automatically.
