Makita 5704R Technical Information

Repair
P 3 / 5
-5 °
20 °
Fig. 4
( 4 ) Assembling lever plate
Lever plate's angle against base has to be as illustrated in Fig.4, when the machine is adjusted
to max. cutting depth.
( 1 ) Disassembling gear section
After removing ball bearing 608ZZ, hold ring 12 installed to bearing box, with 1R031"bearing setting pipe".
And disassemble spindle by pressing it down with arbor press as illustrated in Fig. 5.
So, the gear section can be disassembled as illustrated in Fig. 5A.
Do not forget to assemble 2 pcs. of flat washers 8 between blade case and depth guide, when assembling
lever plate. See Fig. 4A.
2 pcs. of Flat washers 8
Depth guide
Blade case
Lever plate
Hex nut M8
< 2 > Replacing gear section
Fig. 4A
Ring 12 : Hold this part with 1R031
"bearing setting pipe".
1R031 "Bearing setting pipe"
Arbor press
Disassembled spindle
Fig. 5
Sleeve 12
Bearing box
Spindle
Helical gear 49
Ring 12
Fig. 5A
Ball bearing
608ZZ

Makita 5704R Specifications

General

Input power	1200 W
Power source	AC
Blade diameter	190 mm
Idle speed (max)	4900 RPM
Cutting depth (45º)	46 mm
Cutting depth (90º)	66 mm

Weight and Dimensions

Weight	4600 g
