Reparaturanleitung PS-4600 / PS-5000 17
Repair manual DCS3500 / DCS3501 / DCS4300 / DCS4301 / EA3500F / EA3501F / EA4300F / EA4301F / MEA3500L / MEA3500M / MEA4300G / MEA4300L
Screw the disassembly mandrel (chapter 00
pos. 2) onto the threaded end of the shaft.
Do not screw the mandrel all the way down.
Leave about 2 mm between the mandrel and
the flywheel.
Hold the machine in one hand or place on a
soft surface, and knock the flywheel loose with
CAUTION: The cone of the crankshaft must
always be degreased before assembly.
Removing the flywheel
Remove starter see chap. 06.
Block the piston, see chap. 04.
Loosen the nut in the direction of the arrow
and remove it along with the washer.
