Circuit diagram

Color index of lead wires' sheath

Black

Red

Yellow

DC Motor

Line filters

Flag receptacles

Terminal

Part No. 638862-2: with Line filters and Flag receptacles

Part No. 638887-6: without Line filters and with Flag receptacles

Note: The difference of the above specifications is based on

the regulations by country or area.

Switch unit

Fig. D-1

Switch

P 5/ 6

(Housing L side)

(Housing R side)

Other manuals for Makita HP457D

Questions and Answers:

Need help?

Do you have a question about the Makita HP457D and is the answer not in the manual?

General

Voltage	18V
Chuck Capacity	13 mm
Weight	1.7 kg
Power Source	Cordless
Max Drilling Capacity in Steel	13 mm
Max Drilling Capacity in Wood	36 mm
Max Drilling Capacity in Masonry	13 mm
Torque Settings	16 + Drill
Max Fastening Torque (Hard)	42 Nm
Type	Combi Drill
No Load Speed	0-400 / 0-1, 400 RPM
Impact Rate	0 - 6000 / 0 - 21000 ipm
