V-grooving bit
θθ
D
L
2
L
1
A
Fig.60
D A L1 L2 θ
1/4″ 20 50 15 90°
Unit:mm
Drill point ush trimming bit
Fig.61
D A L1 L2 L3
8 8 60 20 35
6 6 60 18 28
1/4″
Unit:mm
Drill point double ush trimming bit
Fig.62
D A L1 L2 L3 L4
8 8 80 95 20 25
6 6 70 40 12 14
1/4″
Unit:mm
Corner rounding bit
Fig.63
D A1 A2 L1 L2 L3 R
6 25 9 48 13 5 8
1/4″
6 20 8 45 10 4 4
1/4″
