Makita RT0702C User Manual

20 ENGLISH
Chamfering bit
Fig.64
D A L1 L2 L3 θ
6 23 46 11 6 30°
6 20 50 13 5 45°
6 20 49 14 2 60°
Unit:mm
Cove beading bit
Fig.65
D A L1 L2 R
6 20 43 8 4
6 25 48 13 8
Unit:mm
Ball bearing ush trimming bit
Fig.66
D A L1 L2
6 10 50 20
1/4″
Unit:mm
Ball bearing corner rounding bit
Fig.67
D A1 A2 L1 L2 L3 R
6 15 8 37 7 3.5 3
6 21 8 40 10 3.5 6
1/4″ 21 8 40 10 3.5 6
Unit:mm

Makita RT0702C Specifications

General

Variable Speed Control	Yes
Base Type	Fixed
Power Source	Corded
Voltage	120V
Collet Capacity	1/4"
Weight	1.8 kg
Amperage	6.5 Amps
Tool Length	274 mm
Net Weight	1.8 kg
