Makita UC3551A User Manual

8
DESIGNATION OF PARTS
(Nut model: the sprocket cover is tightened by nuts.)
For Model UC3050A, UC3550A, UC4050A, UC4550A
1
2
3
4
5
6
9
10
8
014372
(Lever model: the sprocket cover is tightened by lever.)
For Model UC3051A, UC3551A, UC4051A, UC4551A
1
2
3
4
5
6
9
10
8
7
014373

Makita UC3551A Specifications

General

Power source	AC
Idle speed	7500 RPM
Chain gauge	1.3 mm
Chain pitch	3/8 \
Chain speed	14.5 m/s
Blade length	320 mm
Product color	Black, Turquoise
Automatic oiling	Yes
Chain bar length	350 mm
Oil tank capacity	0.2 L
Kickback protection	-
Noise level	101.8 dB
Uncertainty K	1.5 m/s²
Standard deviation	2.5 dB
Vibration emission	3.9 m/s²
Sound pressure level	90.8 dB

Weight and Dimensions

Width	201 mm
Height	220 mm
Length	505 mm
Weight	5500 g
