NanoSampler hardware
28
Plates and vials
The NanoSampler uses 2 x 48 well trays, each well of which holds a single 1.5mL vial.
The system can be loaded with either one or two trays, each of which can contain any
number of vials (up to 48) as required by your analysis.
Caution: only use vial holder plates supplied by Malvern Instruments. This is
due to varying pitches of plates from different manufacturers, which could res-
ult in damage to the needle.
Using the hardware
Opening the door
To load samples into the NanoSampler, open the door using the following procedure:
1. Hold the door handle and gently pull upwards until in it is in a horizontal pos-
ition:
