21 SPARE PART LIST
Wear, tear and replacement part requirements depend on specific operating conditions.
The recommended quantities are based on experience and are not binding.
Converter CG...
(C) Consumable parts, (R) Recommended spare parts and
(S) Spare parts
recommended quantity CG
beeing in operation [years]
(a.r. = as required)
C/R/S
1
2
3
95 A 9003
Catalyst cartridge CG-2-C
C
a.r.
a.r.
a.r.
95 A 9004
Catalyst cartridge CG-2-SS
C
a.r.
a.r.
a.r.
95 A 9070
O-ring set for CG-2
S
-
-
1
95 A 9040
Control board compl. CG – 230 V
S
-
-
1
95 A 9040a
Control board compl. CG – 115 V
S
-
-
1
95 A 9057
Heater CG2, 230 V 50/60 Hz
S
-
-
1
95 A 9057a
Heater CG2, 115 V 50/60 Hz
S
-
-
1
01 B 8401
Temperature controller CG, Typ 70304
S
-
-
1
90 K 6045
Fan 80 x 80, 24 V
C
-
1
2
05 V 1060
Male connector G1/4“-DN4/6
PVDF
R
2
4
4
05 V 6600
Ferrule 4/6 PV
R
5
10
15
05 V 6605
Union nut M10-4/6 PV
R
4
8
10
22 APPENDIX
• Wiring plan CG-2M,
Drawing No. : 2224-5.04.0
• Wiring plan CG-2MH-W,
Drawing No. : 2224-5.04.4
• Wiring plan CG-2H-W,
Drawing No. : 2224-5.04.5
For further product documentation, please see our internet catalogue:
www.mc-techgroup.com
