M&R Challenger 2 User Manual

V.033114
M&R Companies 1N 372 Main St. Glen Ellyn, IL 60137 USA 15
Tel: +630-858-6101 Fax: +630-858-6134 www.mrprint.com | store.mrprint.com
6.1 Main Control Panel
Number
Name
Function
1
Print
Button
Permits manual cycling of an individual print station. The Print button is also
used during screen frame setup to check registration. During setup, press the
Print button. The index carousel moves up so that screen registration or
placement may be checked. To lower the index carousel, press the Reset
button (9).
The Print button also functions in a Standard or Enhanced mode. These
functions are explained in the Operator Interface Section of this manual.
2
Single/Multi
Switch
Commands the selected print station to print either one or up to nine complete
flood/print cycles. This switch is used when a thicker coating of ink is required,
such as in flash cure applications, or whenever increased ink opacity is
desired. Each individual print head in the system may be set independently for
either Single or Multi print stroke. (MULTI print is set in the OPTIONS screen
on the Operator Interface.)
Note: When this switch is selected for the middle, or Off position, the particular print
station will not operate.
3
Test Print
Switch
Aids the operator when printing only one garment to check for registration or
image quality. When placed in the On position, the control system will
automatically and sequentially command each print station which is selected to
On to print one complete flood/print cycle.
