2 - 9
A - GROUND CONTROL POINT
1 - EMERGENCY STOP
2 - KEY SWITCH FOR SELECTION OF CONTROLS ON THE GROUND OR ON THE ACCESS
PLATFORM
3 - OVERLOAD LAMP
4 - “MAINTENANCE MACHINE” LAMP AND VARIATOR DEFECTS
5 - INCLINATION CONTACTOR OF THE PLATFORM
6 - ROTATION CONTACTOR OF THE PLATFORM
7 - RAISE AND LOWER CONTACTOR OF THE EXTENSION ARM
8 - ROTATION SWITCH FOR ROTATING JIB (OPTION)
9 - OUTPUTS AND INPUTS CONTACTOR OF THE TELESCOPE
10 - RAISE AND LOWER CONTACTOR OF THE SUPERIOR ARM
11 - LOWER ARM LIFTING AND LOWERING SWITCH
12 - INDICATOR OF CHARGE OF THE BATTERY AND THE HORAMETER
13 - TURRET ROTATION CONTACTOR
14 - "DEAD MAN" BUTTON
15 - BATTERY SWITCH
16 - FLASHING LIGHT (OPTION)
17 - SLOPE SENSOR
18 - “STATE OF CHARGE OF THE BATTERY” LAMP
19 - SOUND ALARM HORN
20 - TURRET ROTATION BLOCKAGE
