A1 - FUNCTION OF THE HORAMETER
Before any action in the main unit, switch off the power at the battery
switch, and get a qualified person.
THE HORAMETER ON THE FRONT OF THE MAIN UINIT
- This counts the number of hours of operation of the machine.
- The dial 1 (Fig. A1/1) indicates the number of hours effected by the
access platform.
- There is also a timer which triggers the operation of the orange lamp (Fig.
A1/1) every 50 hours.
It is possible to reset the timer to zero.
(see the following paragraph)
A2 - ZERO RESET OF THE TIMER
This setting is performed after first doing the maintenance operation
described in the chapter entitled: “EVERY 50 HOURS OF OPERATION”.
Proceed as follows :
- The lifting platform must be in transport position (arm and telescopic
unit fully retracted),
- The platform must not be on a slope,
- Set th e selector 1 (Fig. A 2/ 1) t o ba se c on tr ol a nd wait fo r the
initialisation 'Beep".
- Press the "Dead Man's" button 2 (Fig. A2/1) while holding down both
contactors 3 (F ig. A 2 / 2 ) a t the s a m e t i m e u n t i l t h e MACHINE
MAINTENANCE light 4 (Fig. A2/3) goes out (the timer is reset to zero).
NOTE: This manipulation should be performed during the 3 to 4 seconds
after switching on the electric circuit.
