TYING DOWN THE MACHINE FOR TRANSPORTATION BY TRUCK OR TRAILER
- Always chock the machine’s wheels in preparation for transport.
- Retract and tie down the lifting platform’s extension unit.
- Use the tie-down points on the chassis to fasten the machine to the truck bed’s surface
(Figs. E and F).
- Use at least two chains or straps.
- Use chains or straps with sufficiently large load-retaining strength.
- Fasten chocks to the truck bed in front of and behind each of the lifting platform’s tyres
1 (Fig. E).
- Also fasten chocks to the truck bed on the inside and outside of each tyre 1 (Fig. F).
- Turn the ignition switch to the OFF position and remove the key before transport.
- Inspect the whole machine to discover any loose or poorly fastened elements.
- If the ramps have been folded, tie them down with straps before transport.
UNLOADING
Please adapt the lifting platform’s translation speed by controlling it
with the translation joystick.
598895 598895
F
598895 598895
E
598895 598895
F
598895 598895
E
78 SEC
100 SEC
120 SE
78 SEC
100 SEC
120 SE
1
1
1
1
1
1
1
1
1
1
1 1
647369 (01/03/2017) 78/100 SEC 2 / 120 SE 2
