Manitou 78 SEC 2 User Manual

2-41
RELEASING THE BRAKES
The lifting platform may only be towed over a short distance and
necessarily by a machine with significant braking power in order to be
able to hold it and with a connecting bar between the two machines.
- To put the lifting platform into freewheeling mode, the platform must not be subject
to any translation stresses caused by a slope. The wheels must be able to turn freely.
- Push the brake release button to open the brake valve 1 (Fig. B) on the block 3 (Fig. C).
- Press the brake release pump button 2 (Fig. B).
- We would advise against towing lifting platforms 78 SEC - 100 SEC and 120 SE.
- If the machine must be towed, do not exceed 3.2 km/h.
B
C
1
2
3
647369 (01/03/2017) 78/100 SEC 2 / 120 SE 2
