3-18
C6 - Overload
CHECK
- The overload must activate at between 1.1 and 1.2 times the nominal load (see CHAPTER 2 - General characteristics).
Expected result:
• 78/100 SEC-2 > Nominal load 227 Kg: activation load between 249 kg and 272 kg
• 120 SE-2 > Nominal load 318 Kg: activation load between 349 kg and 381 kg
- The overload sensors must activate at the same time.
Refer to the repair manual for information about adjusting the overload
In the case of malfunction, forbid usage of the nacelle. Consult your dealership.
C7 - Stopping distance
CHECK
Proper brake action is essential to safe machine operation. The drive brake function should operate smoothly, free of hesitation, jerking
and unusual noise. Hydraulically-released individual wheel brakes can appear to operate normally when they are actually not fully
operational.
- Mark a test line on the ground for reference.
- Start the engine from platform controls.
- Choose a point on the machine; i.e., contact patch of a tire, as a visual reference for use when crossing the test line.
- Bring the machine to maximum drive speed before reaching the start line. Release the function enable switch on the joystick or release
the joystick when your reference point on the machine crosses the test line.
- Measure the distance between the test line and your machine reference point.
Expected result:
On horizontal ground
Stopping distance
Transport speed 610 mm +/- 300 mm
CHECK BRAKE HOLDING ON A SLOPE
- The brakes must be able to hold the machine on any slope it is able to climb.
647369 (01/03/2017)
78/100 SEC 2 / 120 SE 2
