Manitou Mara Inline - Install Piston Quad Ring; Seat Piston Quad Ring; Install Piston Split Glide Ring

15
50 HOUR AIR CAN & PISTON GUIDE
AIR piston service
8
9
10
Install the air piston quad ring
onto the air piston.
Ensure the air piston quad ring
is not twisted and push it tight
against the glide ring, making
a space for the split glide ring.
Install the split glide ring onto
the air piston.
