50 HOUR AIR CAN & PISTON GUIDE
AIR piston service
1
2
3
Remove the split glide ring
from the air piston.
Remove the air piston quad
seal. DO NOT REMOVE WHITE
GLIDE RING! Clean the white
glide ring and air piston with
isopropyl alchohol.
Liberally grease the air piston
quad ring.
