Manitou Mattoc Pro Service Manual

16
MATTOC PRO SERVICE MANUAL
AIR SPRING SERVICE
4
5
Remove Air Spring Assembly, clean with
isopropyl, and re-grease.
Once the air spring assembly is removed
clean the inside of the stanchion with
isopropyl alcohol and a lint free towel (Be
careful to not scratch the inner surface
of the stanchion). Inspect the inside and
outside of the stanchion for scratches or
other damage.
3
Invert the fork and use Manitou cassette
tool with adjustable wrench to unthread
the air spring assembly from the
stanchion.

Manitou Mattoc Pro Specifications

General

Spring Type	Air
Travel	160mm
Wheel Size	27.5", 29"
Adjustments	Rebound, low-speed compression
Axle	15mm thru-axle
Steerer Tube	1.5" tapered
