15
MATTOC PRO SERVICE MANUAL
AIR SPRING SERVICE
1
2
3
Make sure the air is released from the
fork. Depress IRT and Compression Rod
Schrader valves a few times to ensure
all air is released.
Remove IRT using a 24mm socket.
Pull IRT assembly straight out.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Manitou Mattoc Pro and is the answer not in the manual?

Manitou Mattoc Pro Specifications

General IconGeneral
Spring TypeAir
Travel160mm
Wheel Size27.5", 29"
AdjustmentsRebound, low-speed compression
Axle15mm thru-axle
Steerer Tube1.5" tapered
