21
MATTOC PRO SERVICE MANUAL
DAMPER SERVICE
4
3
With a 13mm socket, unthread the
exposed nut and remove the red low
speed adjustment knob.
Note: Be sure to hold the knob still while
removing the screw/nut. These tend to
move and can damage the damper if the
knob is over turned.
Remove the sliver spacer that was under
the red low speed adjustment knob.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Manitou Mattoc Pro and is the answer not in the manual?

Manitou Mattoc Pro Specifications

General IconGeneral
Spring TypeAir
Travel160mm
Wheel Size27.5", 29"
AdjustmentsRebound, low-speed compression
Axle15mm thru-axle
Steerer Tube1.5" tapered
