MATTOC PRO SERVICE MANUAL
9
8
10
DAMPER SERVICE
Using a Manitou cassette tool and
adjustable wrench, unthread the
rebound damper assembly from the fork
stanchion.
Remove rebound damper assembly from
the fork. Once the damper assembly
is removed, clean the inside of the
stanchion with isopropyl alcohol and a
lint free towel. Inspect the inside and
outside of the stanchion for scratches
and other damage. Inspect rebound
damper for damage and replace if
necessary.
Use a 26mm crow’s foot, Manitou
cassette tool, and torque wrench to
install the rebound damper assembly.
Torque to 60-80 in lb [6.8-9.0 N m

Manitou Mattoc Pro Specifications

General

Spring Type	Air
Travel	160mm
Wheel Size	27.5", 29"
Adjustments	Rebound, low-speed compression
Axle	15mm thru-axle
Steerer Tube	1.5" tapered
