SERVICING SCHEDULE

IMPORTANT

(1): COMPULSORY 500 HOUR OR 6 MONTH SERVICE. This service must be carried out after approximately the first 500 hours of operation or within the 6 months following
the start-up of the machine (whichever occurs first).
(2): Consult your dealer.
A = ADJUST, C = CHECK, D = RECHARGE, G = GREASE,
N = CLEAN, P = BLEED, R = REPLACE, V = DRAIN
PAGE (1)
DAILY OR EVERY
10HOURS OF SERVICE
EVERY 50 HOURS OF
SERVICE
EVERY 250 HOURS
OF SERVICE
EVERY 500 HOURS
OF SERVICE OR
EVERY YEAR
EVERY 1000 HOURS
OF SERVICE OR
EVERY TWO YEARS
EVERY 2000 HOURS
OF SERVICE OR
EVERY TWO YEARS
EVERY 4000 HOURS
OF SERVICE
OCCASIONAL
ELECTRICITY
-Battery 3-10 D D
- Battery electrolyte level 3-10 C C
- Cleaning the battery 3-11 C C
-
Electrolyte level of all battery cells
3-12 C C
- Battery electrolyte specific gravity. 3-12 C C C(2)
- Condition of control panels
3-16 C C C(2)
- Battery insulation resistance
3-18 C C C(2)
- Condition of wiring harness and cables C(2)
- Warning indicators C(2)
- Lights and signals C(2)
- Steering potentiometer C(2)
- Remove the battery tray
3-22
XXX
TRANSMISSION
- Transfer gearbox oil 3-16 C C
- Transfer gearbox oil 3-20 V V
REAR AXLE
- Swivel pins 3-12 G G
C/G(2)
- Rear axle
C(2)
STEERING
- Steering connecting rod 3-12 G G
- steering C(2)
TYRES
- Wheel nut tightening 3-13 C C
- Condition of wheels and tyres C(2)
MAST
- Tension and alignment of the mast lifting chains 3-13 C/A C/A
- Mast 3-13 G G
-
Mast lifting chains 3-18 N/C/G N/C/G C(2)
-
Condition of mast unit C(2)
- Chain rollers C(2)
- Mast guide rollers C(2)
- Mast bearing rollers C(2)
- Thickness of the mast wearing plates C(2)
HYDRAULIC SYSTEM
- Hydraulic oil level 3-14 C C
- Hydraulic oil 3-20 V
- Suction strainer for hydraulic oil tank 3-20 N
- Hydraulic return oil filter 3-20 R
- Condition of cylinders (leakage, rods) C(2)
- Speeds of hydraulic movements C(2)
- Condition of hoses and flexible pipes C(2)
- Hydraulic oil tank N(2)
- Hydraulic circuit pressures C(2)
- Hydraulic circuit outputs C(2)
BRAKING
- Brake oil level 3-14 C C
- Parking brake 3-16 C/A C/A
-
Brake C(2) C(2)
-
Brake oil V(2)
- Brake system P(2)
3-8
647503 (10/05/2017)
M
E 418/420/425C 48V S3
