Manitou MRT-X 2150 Privilege Plus ST3A S2 Operator's Manual

2-13
EN
Main hydraulic pump
Pump Type Gear
Displacement L - cm
3
0.05183 - 51,83
Flow rate @ xxxx rpm l/mn 114
Pressure bar - psi 270 - 3916.019
Secondary hydraulic pump
Pump Type Gear
Displacement L -cm
3
0.01685 -16,85
Flow rate @ 2200 rpm l/mn 37
Pressure bar - psi 300 - 4351,13
Main electrovalves
Lifting circuit l/min 100
Extension circuit l/min 100
Slewing circuit l/min 40
Tilting circuit l/min 100
Frame leveling l/min -
Locking rear axle l/min -
Stabilizers l/min -
Turret locking l/min -
Optional circuit l/min 65
Steering circuit
Pump Type Load sensing
Displacement L - cm
3
-
Flow rate @ xxxx rpm l/mn -
Pressure bar - psi -
Brake circuit
Type Servo-assisted
Pressure bar - psi -
TRANSMISSION
Transmission unit
Gearshift Mechanical with hydraulic control
Nb of forward gears 2
Nb of reverse gears 2
Reverser Electromagnetic
Brakes
Type Disc in oil bath
Foot brake Acts on the front and rear wheels
Parcking brake Hydraulic with negative action on the front axle
Front axle
Type Steering
limited slip system -
Final drives Epicyclic
Rear axle
Type Steering
Limited slip system -
Final drives Epicyclic
Standard Front & Rear tyres
Type AEOLUS
Dimensions 445/65R22.5 Tl agp23
Pressure bar - psi 8,0 - 116
Type MITAS
Dimensions 445/65R22.5 Ar01
Pressure bar - psi 8,0 - 116
Type MICHELIN
Dimensions 445/65-R22.5 Xzy3
Pressure bar - psi 9,0 - 130,5
2-13

Manitou MRT-X 2150 Privilege Plus ST3A S2 Specifications

General

Brand	Manitou
Model	MRT-X 2150 Privilege Plus ST3A S2
Category	Construction Equipment
Language	English
