SPECIFICATIONS AND WEIGHTS
MRT 2150 Privilege Plus ST4 S2
MRT-X 2150 Privilege Plus ST3A S2
MRT 2550 Privilege Plus ST4 S2
MRT-X 2550 Privilege Plus ST3A S2
Driving speed
Maximum speed: km/h - mph 40 - 24.85
Forward unloaded km/h - mph 40 - 24.85
With nominal load km/h - mph 5 - 3.1
Reverse unloaded km/h - mph 40 - 24.85
With nominal load km/h - mph 5 - 3.1
Lifting capacity
Standard lifting height on tyres m - ft 20,7 - 67.9 21,8 - 71.5
Standard lifting height on stabs m - ft 20,97 - 68.8 25,78 - 84.5
Lifting heigt at max capacity on tyres m - ft 9,8 - 32 14 - 45.9
Lifting heigt at max capacity on stabilizers m - ft 12,3 - 40.3 14,2 - 46.5
Forward reach at max capacity on tyres m - ft 4,9 - 16 5,75 - 18.8
Forward reach at max capacity on stabilizers m - ft 7,5 - 24.6
Max rated capacity with STD carriage and forks kg - lb 4999 - 11020
Distance from center of gravity mm - in 500 - 19.6
Capacity at max height with STD carriage and forks on tyres kg - lb 2000 - 4409
Capacity at max height with STD carriage and forks on stabilizers kg - lb 2500 - 5511.55 2000 - 4409
Capacity at max reach with STD carriage and forks on tyres kg - lb 300 - 661.38 100 - 220.46
Capacity at max reach with STD carriage and forks un stabilizers kg - lb 800 - 1763.69 400 - 881.84
Weight distribution with STD carriage and forks
Truck weight without attachment kg - lb 17480 - 38536.76 18470 - 40719.33
Front axle weight without attachment kg - lb 7780 - 17151.94 7750 - 17085.8
Rear axle weight without attachment kg - lb 9700 - 21384.81 10720 - 23633.53
Truck weight with STD carriage and forks (unloaded) kg - lb 17930 - 39528.84 18900 - 41667.32
Front axle weight with STD carriage and forks (unloaded) kg - lb 8710 - 19202.24 8700 - 19180.19
Rear axle weight with STD carriage and forks (unloaded) kg - lb 9220 - 20326.6 10200 - 22487.12
Max load on each stabilizer kg - lb 12500 - 27557.75
Max load per tyre kg - lb 8510 - 18761.32 8710 - 19202.24
Maximum ground pressure kg/cm
2
9
9
Pulling capability
Tractive force (Drawbarpull) daN - kgf 8700 - 8871.53 8800 - 8973.50
Break out force with bucket (according to standard ISO 8313) - -
Gradeability
Unloaded % -
Loaded % -
Turret
Slewing turret deg. 360°
Locking system type Manual pin
Outriggers
Type Articulated
Nb 4
Contrôle Individual or simultaneous control
Hydraulic motions speeds
Unladen lifting s 27 34
Laden lifting s - -
Unladen lowering s 22 24
Laden lowering s - -
Unladen extending s 32 39
Laden extending s - -
Unladen retracting s 23 38
Laden retracting s - -
Reverse tilt time unladen s 7 8,5
Forward tilt time unladen s 8 8,5
Turret rotation clockwise (360°) s 26 21
Turret rotation counterclockwise (360°) s 26 21
