2 - 37
HORIZONTAL SHOCK ABSORBER (FIG. H)
In certain conditions (e.g. driving with a trailer) it is advised that a horizontal shock
absorber be used. The driver’s seat is thus better able to absorb jerks in the direction
of travel.
• Position 1: Horizontal shock absorber fitted.
• Position 2: Horizontal shock absorber removed.
LONGITUDINAL ADJUSTMENT (FIG. I)
- Adjust the locking lever until you reach the position required. This then locks and
the seat will not shift into another position.
SERVICING (FIG. J)
IMPORTANT
A rocking head-rest increases the risk of an accident !
Dirt may adversely affect the correct functioning of the seat. For this reason, make sure
your seat is always clean.
- To clean or change the cushions, simply remove them from the seat frame.
- Avoid wetting the cushion fabric when cleaning. Check the resistance of the fabric
on a small hidden area before using any fabric or plastic cleaner.
I
J
H
2 - SEAT BELT
IMPORTANT
In no event should the lift truck be used if the seat belt is defective (fixing, locking, cuts, tears, etc.).
Repair or replace the seat belt immediately.
- Sit correctly on the seat.
- Check that seat belt is not twisted.
- Place the seat belt at hip level.
- Attach the seat belt and check that it locks.
- Adjust the seat belt to your body shape without squeezing your hip and without over-slack.
3 - IGNITION SWITCH
The key switch has five positions:
• P - Not used.
• O - Ignition switched off and engine stopped.
• I - Ignition + preheating.
• II - Not used.
• III - The engine starts, return to position I as soon as the key is released.
647104 (13/06/2016)
MT 835 / 1135 / 1335 ST3B
