H3 – FRONT HEADLIGHTS
ADJUST
RECOMMENDED SETTING
(as per standard ECE-76/756 76/761 ECE20)
Adjustment of -2 % of the dipped beam relative to the horizontal
axis of the headlight.
ADJUSTMENT PROCEDURE
- Place the unladen lift truck in the transport position and
perpendicular to a white wall on flat, level ground.
- Check the tyre pressures (see: 2 - DESCRIPTION: FRONT AND
REAR TYRES).
- Place the forward/reverse selector in neutral.
CALCULATING THE HEIGHT OF THE DIPPED BEAM (H2)
• h1 = Height of the dipped beam in relation to the ground.
• h2 = Height of the adjusted beam.
• l = Distance between the dipped beam and the white wall.
H4 – BATTERY FAILURE
CHANGE

IMPORTANT

Operate the battery cut-off no less than 30 seconds after having switched off the ignition with the ignition key.
Handling and servicing a battery can be dangerous, take the following precautions:
- Wear protective goggles.
- Keep the battery horizontal.
- Never smoke or work near a naked flame.
- Work in a well-ventilated area.
- In the event of electrolyte being spilled onto the skin or splashed in the eyes, rinse thoroughly with cold water for
15minutes and call a doctor.
- Remove the protective casing and the toolbox 1 (OPTION) .
- Bring a backup battery of the same type as that of the lift truck, together with
battery cables.
- Connect the backup battery with the correct (-) (+) polarity.
- Start the lift truck and remove the cables as soon as the engine is running.

IMPORTANT

Raise the boom and place the boom safety wedge on the rod of the lifting cylinder (see: 1 - OPERATING AND SAFETY
INSTRUCTIONS: LIFT TRUCK MAINTENANCE INSTRUCTIONS).
- Remove the protective casing 2.
- Change the battery 3.
H5 – LIFT TRUCK
TOWING

IMPORTANT

Do not tow the lift truck at more than 25 km/h.
- Place the forward/reverse selector in neutral and the gear shift in neutral.
- Release the hand brake.
- Switch on the hazard warning lights.
- Since there will be no steering or braking hydraulic assistance, operate the steering and pedal slowly avoiding sudden
or jerky movements.
3 - 36
1
2
3
+%
-%
h1
h2
-2%
h2 = h1 - (l x 2 / 100)
h1
l
647449 (30/11/2015) MT 732/932 ST3B
