DESCRIPTION
1 - DRIVER'S SEAT
2 - SEAT BELT
3 - CONTROL AND SIGNAL LIGHTS PANEL
4 - LONGITUDINAL STABILITY LIMITER AND WARNING DEVICE
5 - EMERGENCY STOP BUTTON
6 - SWITCHES
7 - LIGHTING, HORN AND INDICATOR LIGHTS
8 - FRONT AND REAR WINDSCREEN WIPER SWITCH
9 - IGNITION SWITCH
10 - FUSES AND RELAYS IN THE CAB
11 - FUSES AND RELAYS UNDER THE ENGINE BONNET
12 - DIAGNOSTIC PLUG
13 - ACCELERATOR PEDAL
14 - SERVICE BRAKE PEDAL AND TRANSMISSION CUT-OFF
15 - GEAR LEVER AND TRANSMISSION CUT-OFF
16 - PARKING BRAKE LEVER
17 - FORWARD/NEUTRAL/REVERSE GEAR SELECTION
18 - STEERING SELECTION
19 - HYDRAULIC CONTROLS
20 - FUNCTION FILES
21 - LEVEL INDICATOR
22 - HEATER CONTROL
23 - AIR CONDITIONING CONTROLS (AIR CONDITIONING OPTION)
24 - CAB VENTILATION FILTER
25 - WINDSCREEN DEMISTER VENTS
26 - HEATING VENTS
27 - BRAKE OIL AND WINDSCREEN WASHER TANK ACCESS PANEL
28 - DOOR LOCK
29 - LOCKING HANDLE FOR UPPER HALF-DOOR
30 - UNLOCKING BUTTON FOR UPPER HALF-DOOR
31 - HANDLE FOR REAR WINDOW OPENING
32 - STORAGE COMPARTMENT
33 - SUN VISOR (OPTION)
34 - ROOF LIGHT
35 - HOOK
36 - CIGARETTE LIGHTER
37 - ARMREST AND STORAGE
38 - TOOL BOX (OPTION)
39 - BATTERY CUT-OFF
40 - FRONT HEADLIGHTS (NOT ILLUSTRATED)
41 - REAR LIGHTS (NOT ILLUSTRATED)
42 - ROTATING BEACON LIGHT (NOT ILLUSTRATED)
43 - BOOM SAFETY WEDGE
NOTE: All the terms such as: RIGHT, LEFT, FRONT, REAR are as seen by an observer seated on driver's seat and looking straight
ahead.
