DRIVER'S PNEUMATIC SEAT (OPTION)
DESIGNED FOR MAXIMUM COMFORT, THIS SEAT CAN BE ADJUSTED AS FOLLOWS.
SEAT HEIGHT ADJUSTMENT
- Sit down correctly in the seat.
- Switch on lift truck ignition.
- Pull or push lever 1 according to the desired height, making sure that the green
indicator lamp 2 remains visible.
- If indicator lamp 2 is red, re-adjust the height.
NOTE: The seat is designed so as not to require adjustment according to the driver's
weight.
LONGITUDINAL ADJUSTMENT
- Swing lever 3 upwards.
- Slide the seat to the desired position.
- Release the lever and be sure it returns to the lock position.
HORIZONTAL SHOCK ABSORBER
In certain conditions (e.g. driving with a trailer) it is advised to use the horizontal shock
absorber. The driver’s seat is thus better able to absorb jerks in the direction of travel.
- Swing lever 3 downwards to block the horizontal damper.
BACK-REST ANGLE ADJUSTMENT
- Hold the back-rest, push lever 4 backwards and tilt the back-rest to the desired position.
IMPORTANT
If you do not support the back-rest when making adjustments, it swings completely forwards.
EXTENDING THE HEAD-REST
- The height of the head-rest 5 can be adjusted by pulling it upwards (the notches will click) up to the stop.
- The head-rest can be removed by applying sufficient pressure to pull it off the stop.
LUMBAR ADJUSTMENT
- Turn knob 6 anti-clockwise to select one of the 5 lumbar support settings.
SEAT HEATING
- Switch 7 operates the heating of the seat cushion and the back-rest.
1
2
6
5
3
4
7
