2 - 42
10 - FUSES AND RELAYS IN THE CAB
A sticker on the inside of the access panel provides a quick indication of the use of the
fuse plate's components described below.
- Remove access panel 1 to gain access to the fuses and relays, Replace a used fuse
with a new fuse of the same quality and capacity. Never reuse a repaired fuse.
MINIFUSE
• F1 - Hydraulic control unit (7,5A).
OPTION.
• F2 - Rear working lights (15A).
• F3 - Rear windscreen wiper + OPTION roof windscreen wiper + OPTION side
windscreen wiper (10A).
• F4 - Engine and cab electronic control unit (7,5A).
• F5 - Rotating beacon light (7,5A).
• F6 - Wheel alignment (5A).
OPTION.
• F7 - Longitudinal stability limiter and warning device (7,5A).
Disabling of “aggravating” hydraulic movement cut-off
(7,5A).
OPTION Blue front and rear working lights (15A).
• F8 - Forward/neutral/reverse gear selection (15A).
Transmission cut-off (15A).
Reversing lights (15A).
Reversing sound alarm (15A).
• F9 - Control panel (5A).
• F10 - Sound alarm (10A).
Stop switch (10A).
• F11 - OPTION Head telescope working lights (15A).
• F12 - Flashing unit (10A).
• F13 - Ventilation/heating (20A).
• F14 - Cigarette lighter (25A).
OPTION.
• F15 - Hydraulic movement control unit (20A).
• F16 - Diagnostic plug (5A).
Ventilation/heating relay control (5A).
• F17 - OPTION Self-cleaning fan (10A).
OPTION MODCOD / MODCLÉ Anti-theft system (10A).
• F18 - Front working lights (15A).
• F19 - OPTION Rear windscreen defrost (15A).
• F20 - OPTION Pneumatic seat (15A).
• F21 - Front windscreen wiper and front windscreen washer (10A).
• F22 - OPTION Boom suspension (10A).
OPTION Boom electrical predisposition (5A).
OPTION Head telescope electrovalve (7,5A).
• F23 - Right sidelights (7,5A).
Dashboard lighting (7,5A).
• F24 - Left sidelights (7,5A).
Number plate lighting (7,5A).
• F25 - Right indicator lights (7,5A).
• F26 - Left indicator lights (7,5A).
• F27 - Dipped beam headlights (15A).
Dipped beam headlights indicator lamp (15A).
Rear fog lights (15A).
• F28 - Main beam headlights (15A).
Main beam headlights indicator lamp (15A).
1
K5 K6
K9K8
K7
K4K3K2
K1K0
F30F26 F27 F28 F29F16 F17 F18 F19 F20 F21 F22 F23 F24 F25
15A max10A15A max15A 15A max 5A 7.5A7.5A 15A7.5A 15A 15A15A 25A7.5A
OPT.OPT.
DIAG
OPT.OPT.
F15F1 F2 F3 F4 F5 F6 F7 F8 F9 F10 F11 F12 F13 F14
20A25A max20A10A max 15A max10A15A 7.5A 7.5A max 15A max 5A 10A 15A max15A 10A
OPT.
ECU
HYD.
OPT.
OPT.ECM
N°52505437
K17K18
STOP
OPT.
OPT.
LSU
OPT.
OPT.
F33 F32 F31
2A 5A 5A
DIAG
SPU
TEST
N
647449 (30/11/2015) MT 732/932 ST3B
