Manitowoc 1400A - Page 116

OUTRIGGERS SERVICE MANUAL1400A
7-2 1-21-2019 Control # 104-07
Lock Pin
FIGURE 7-1
1
ST
Section Beam
2
ND
Section Beam
Extend Cylinder
Anchor Bolts
Top Cable
Adjustment
Outrigger
Box
Outrigger Float
Bottom Cable
Adjustment
Stabilizer
Hydraulic LInes
Fo
r
Reference
Only
