HYDRAULIC SYSTEM SERVICE MANUAL 1400A
2-8 1-21-2019 Control # 104-07
5 Rear Outrigger Solenoid Manifold
6 Front Outrigger Solenoid Manifold
7 Outrigger Pressure Reducing Valve
8 Swing Speed Control Valve
9 Hydraulic Remote Control Valve
Item Component
5
FIGURE 2-1
4
1a
3
2
5
7
6
8
Item Component
1a Main Control Valve (lift, telescope, hoist)
1b Main Control Valve (Optional Aux Hoist)
2 Swing Control Valve
3 Swing Brake Manifold
4 HRC Dump Manifold
1b
9
Fo
r
Reference
Only

Manitowoc 1400A Specifications
