Manitowoc 1400A User Manual

National Crane 1-21-2019 Control # 104-07 5-9
1400A SERVICE MANUAL HOIST
5
Item Quantity Description
1 6 Capscrew
2 3 Support Rod
3 6 Capscrew
4 1 Output Gear Set
4-1 1 Output Carrier
4-2 3 Planet Gear
4-3 3 Planet Pin
4-4 3 Retaining Ring
4-5 1 Plate
4-6 6 Bearing
4-7 3 Spacer
4-8 6 Race
51Drum
62Race
7 1 Kit, Seal
7-1 1 O-ring
7-2 1 O-ring
7-3 1 O-ring
7-4 2 Seal, Oil
7-5 1 Seal, Oil
7-6 1 O-ring
7-7 1 Ring, Backup
7-8 1 Ring, Backup
7-9 Omit Omit
7-10 1 O-ring
8 1 Input Sun Gear
9 8 Capscrew
10 1 Brake Piston
11 4 Capscrew
12 1 Kit, Counterbalance, Motor
12-1 1 Counterbalance Valve
12-2 1 Block, Valve
12-3 3 Capscrew
12-4 1 Motor
12-5 2 O-ring
13 1 Brake Driver
14 2 Race
15 2 Retaining Ring
16 1 Output Sun Gear
17 2 Bushing
18 7 Friction Disc
19 8 Stator Plate
20 1 Brake Cover
21 1 Brake Housing
22 Omit Omit
23 2 Retaining Ring
24 12 Brake Spring
25 Omit Omit
26 1 Carrier, Bearing
27 1 90 Deg. Adapter
28 2 Ball Bearing
29 1 Sideplate
30 2 Breather
31 1 Plug
33 1 Plug
34 1 Clutch
35 1 Cable Wedge
36 1 Input Gear Set
36-1 1 Input Carrier
36-2 3 Planet Gear
36-3 3 Planet Pin
36-4 3 Retaining Ring
36-5 1 Plate
36-6 3 Bearing
36-7 6 Race
37 1 90 Deg. Adapter
38 1 Input Driver
39 1 Bushing
40 1 Plug
41 1 Sideplate
42 1 Straight Adapter
43 1 Pipe Bushing
44 1 Lock washer
45 1 Straight Adapter
46 1 Hose Assy
47 1 Capscrew
48 1 Retaining Ring
49 1 90 Deg. Adapter
Item Quantity Description
Fo
r
Reference
Only
