OPERATING CONTROLS AND PROCEDURES 777 OPERATOR’S MANUAL
3-14 Published 10-01-12, Control # 044-05 v2
LIMIT BYPASS TEST: Perform the following test to
determine if the boom up limit on your crane can be
bypassed or not:
1. Lower the boom onto blocking at ground level.
2. Have an assistant push the boom stop limit switch
plunger down to trip the boom up limit switch open (see
Section 4 of Crane Service Manual).
3. Rotate limit bypass key (F1) to the bypass position and
hold.
4. Try to boom up SLOWLY — do not raise the boom any
higher than necessary to perform the test:
a. If the boom rises, your boom up limit can be
bypassed.
b. If the boom does not rise, your boom up limit cannot
be bypassed.
5. The test is complete: release the limit bypass key and
the limit switch plunger to the normal operating
positions.
Table 3-1 Bypassable Limit Identification — PRIOR TO CRANE S/N 7771165
Limit
USA and
non-EUROPEAN
EUROPEAN
Limit
Bypass Switch (F1)
(momentary)
Limit
Bypass Switch (F1)
(momentary)
Jib Up Limit
Bypass Switch (F6)
(maintained)
1
Boom Maximum Up
Yes or No
2
No No
Boom Maximum Down Yes Yes No
Block Up (each load drum) Yes Yes No
Bail – Max and Min (each load drum) Yes Yes No
Load Moment Yes Yes No
Luffing Jib Max Up Yes No Yes
Luffing Jib Max Down Yes Yes No
1
Use only for rigging.
2
The boom up limit cannot be bypassed on current production cranes. To determine if the boom up limit can be bypassed on your
crane, perform the test given below.
