Part Number STH025 8/12 177
ICE THICKNESS PROBE (HARVEST INITIATION)
FUNCTION
The ice thickness probe senses ice on the evaporator
and signals the control board to start a harvest cycle.
SPECIFICATIONS
Freeze Time Lock-In Feature
The ice machine control system incorporates a 6
minute freeze time lock-in feature. This prevents the
ice machine from short cycling in and out of harvest.
Maximum Freeze Time
The control system includes a built-in safety which will
automatically cycle the ice machine into harvest after
60 minutes in the freeze cycle.
Maximum Temperature
Maximum temperature for the ice thickness probe is
120 degrees F (49 degree’s C). Do not clean probe in
a dishwasher or expose to temperatures above the
maximum.
