98 Part Number STH025 8/12
EXPORTING DATA TO A FLASH DRIVE
Data can be copied from the control board memory to
a flash drive and used to transfer setup and/or cycle
data to a replacement control board or to transfer
setup information to multiple ice machines. Data may
also be requested by service department personnel for
analysis or as an aid to troubleshooting. The data files
are small and can be attached to an email.
1. Ensure that the ice machine’s power is on.
2. Press the Menu button.
3. Press the Down arrow until Service is highlighted.
4. Press the Checkmark. The Service menu will be
displayed.
5. Press the Down arrow until USB Setup is
highlighted.
The flash drive must be formatted before using,
Refer to page 94 USB Flash Drive Specifications
and Formatting. All files and data are deleted
during the formatting process.
To Next Page
