5.3.2 Replacing the rinse aid canister
For your safety when using the appliance
Before starting work, it is essential that you familiarize yourself with the rules and hazard warnings
specified in 'Working safely with the appliance' on page 113, and follow the instructions given there.
Materials required
■
One empty canister (10 litres) for the ConvoCare rinse aid
■
Enough soft water (approx. 10 litres); (for specification see the 'Water quality' section of the 'Tech‐
nical data' in the Installation manual)
■
ConvoCare K concentrate (0.33 l)
Mix up the ConvoCare rinse aid in the canister
To avoid excessive foaming, follow the procedure below when mixing the ConvoCare K concentrate
with soft water to produce the rinse aid:
1.
Open the empty canister (1).
2.
Fill the canister with soft water (2) until it reaches just be‐
low the 10 litre mark (4).
3.
Then pour 0.33 l of the ConvoCare K concentrate (3)
carefully into the canister (1).
4.
Check the fluid level in the canister:
■
If the level is below the 10 litre mark (4), carefully add
the extra amount of soft water (2) required.
■
If the level is above the 10 litre mark (4), the rinse aid is
a little less concentrated than specified. You can still
use the rinse aid at the lower concentration.
5.
Replace the cap on the canister and tip it up to mix the
liquids together thoroughly.
Replacing the rinse aid canister
1.
Remove the cap from the ConvoCare rinse aid mixing
canister.
2.
■
Locate the canister that is connected by the (green)
tube to the rinse aid connector (F) underneath the appli‐
ance on the left-hand side.
■
Unscrew the (green) supply tube (2) plus suction nozzle
from the located canister.
■
Remove the empty rinse aid canister.
5 Cleaning procedures
User manual 114
