Removing the halogen lamp
1.
Use the socket wrench to remove the four hex bolts on
the oven light.
The special construction means that the assembly of
screws, trim, glass panel and gasket including mount re‐
mains in one piece when the screws are undone.
2.
Take the complete assembly off the cooking-chamber
wall .
3.
Reach through the hole in the cooking-chamber wall into
the reflector housing and pull the halogen lamp out up‐
wards in a straight line.
Fitting the halogen lamp
1.
■
To fit the halogen lamp, follow the steps in the reverse
order that you performed when removing it.
Do not overtighten the screws when refitting, because
this may break the moisture-tight seal for the reflector
housing. (Overtightening the screws may crack the
glass.)
■
When you have finished the job, remove all objects
from the cooking chamber and wipe down or rinse out
the cooking chamber.
6 Servicing procedures
User manual 137
