Grove Published 3-23-2020, Control # 654-04 5-15
GRT655/655L OPERATOR MANUAL SET-UP AND INSTALLATION
5
Hook Block
Dead End
FIGURE 5-15 continued
8 Parts Line - 4 Sheave Hook Block
7 Parts Line - 4 Sheave Hook Block
Boom Nose
Dead End
Lower Boom
Nose Sheaves
To Main Hoist
Hook Block
Sheaves
8993-9
Upper Boom Nose
Sheaves
To Main Hoist
Hook Block
Sheaves
Upper Boom Nose
Sheaves
Lower Boom
Nose Sheaves
8993-10
