Working range
THIS CHART IS ONLY A GUIDE AND SHOULD NOT BE USED TO OPERATE THE CRANE.
The individual crane’s load chart, operating instructions and other instructional plates must be read and understood prior to operating the crane.
141.7 ft main boom 32 ft – 56 ft fixed offset swingaway
180
190
210
220
200
H [ft]
170
160
150
140
130
120
110
100
90
80
70
60
50
40
30
20
10
0
190 170 150 130 110 90 70 50
180 160 140 120 100 80 60 40 30 20 10
Height from the ground in feet
Operating radius in feet from axis of rotation
Boom and extension length in feet
56' EXT.
33' EXT.
141.7
128.8
115.8
102.8
89.8
76.7
63.7
50.5
37.3
10' 2.74"
Dimensions are for largest Grove furnished hook block
and headache ball, with anti-two block activated.
Axis of
Rotation
78
o
Max.
boom
angle
0
o
OFFSET
20
o
OFFSET
40
o
OFFSET
60
o
50
o
40
o
30
o
20
o
10
o
0
o
70
o
