OPERATING CONTROLS AND PROCEDURES CD5520/YB5520 OPERATOR MANUAL
3-24 Published 07-06-2017, Control # 406-03
To Lower the Boom
Press the accelerator pedal to increase the engine speed to
maximum rpm. Slowly push forward on the boom control
lever (Figure 3-35) until the desired lowering speed is
obtained. The further the control is pushed forward the faster
the boom will lower.
FIGURE 3-35
a0866
WARNING
When lifting at high boom angles with an extended boom,
it is crucial to maintain proper side slide pad adjustment.
Visually check the lateral straightness of the boom before
raising the load. Lifting with a boom which is not visually
straight may cause boom failure and could result in injury
or death.
a0582
Reference Only
