30 Part Number STH038 5/12
Step 4 Wait until the clean cycle is complete
(approximately 24 minutes). Then disconnect power to
the ice machine (and dispenser when used).
Step 5 Remove parts for cleaning..
A. Remove the water curtain
• Gently flex the curtain in the center and remove it
from the right side.
• Slide the left pin out.
B. Remove the water trough
• Depress tabs on right and left side of the water
trough.
• Allow front of water trough to drop as you pull
forward to disengage the rear pins.
Disconnect the electric power to the ice machine
at the electric service switch box.
B
C
D
E
A
To Next Page
