12 Replacing components
eikon e2s Service and Repair Manual UL 170
Removing the stirrer motor
1.
Unfasten two M5.5 hex head flange bolts to remove the
jet/impinger plate from the roof of the cavity.
NOTE:
At the rear the jet/impinger plate rests in a bracket.
2.
Remove the jet/impinger plate from the cavity.
3.
Unfasten sixteen (16) M7 hex nuts.
Be careful not to lose the washers.
