MLC80A-1/MLC90A-1/MLC100A-1/MLC100-1 SERVICE/MAINTENANCE MANUAL POWER TRAIN
7
FIGURE 7-12
Item Description
1DEF Tank
2 DEF Supply Module
3 Coolant Control Valve
4 DOC/DPF Module
5 DEF Dosing Module
6 SCR Module
7 DRP
8 Fill Cap
9 Drain Plug
10 Coolant Tee Blocks
