HYDRAULIC SYSTEM MLC80A-1/MLC90A-1/MLC100A-1/MLC100-1 SERVICE/MAINTENANCE MANUAL
2-8
Published 10-09-2020, Control # 259-06
Swing Motors
The swing motor (Figure 2-10) is a 56 cc, bidirectional, fixed-
displacement motor.
Rotating Bed Hydraulic Valves
Item Description
1 Tank Port T1
2 Pressure Port A
3 Pressure Port B
4 Tank Port T2
FIGURE 2-10
Item Description
1 High-Pressure Accessory Valve
2 Main Control Valve
3 Low-Pressure Accessory Valve
FIGURE 2-11
FOR REFERENCE
ONLY
