Manitowoc Multiplex 50GAX04 User Manual

Part Number 020002365 08/25/2015 19
Section 2 Installation
CO
2
Gas and Compressed Air Circuit Diagram
Carbonator
Tank “B”
Legend
— Manual Shut-off Valve
— Check Valve, Ball Type — Manual 3-way Ball Valve — Connection for Optional Kits
Carbonator
Tank “A”
Sugar Free Line & Disconnect
Sugar Base Lines & Disconnects
Sugar Base Lines & Disconnects
Optional
Air/CO
2
Change-
over Valve
Optional
CO
2
Change-over Valve
AB
Optional
Air Compresso
r
Optional Bulk CO
2
Tank
Set at 90-100 psi
(6.2-6.9 bar)
Optional
CO
2
Tank
“A”
Optional
CO
2
Tank
“B”
Pressure Switch
“ON” = 70 psi (4.8 bar
)
“OFF” = 90 psi (6.2 bar
)
Shake
Machin
e
CO
2
Shut-off to
Carbonator Tank
Medium Pressure Regulator
Set at 60 psi (4.1 bar)
Low Pressure Regulator
Set at 15 psi (1 bar)
Shake Machine
Shut-off Valve
Optional CO
2
Regulators
Set at 90-100 psi
(6.2-6.9 bar
)
