WATER TROUGH REMOVAL
SU1000C (SerVend UC-300 Dispenser)
1. Remove the quarter turn fasteners (turn
counterclockwise) securing the trough in place.
2. Pull forward on the water trough until the rear pins
disengage from the water trough.
3. Lift up and forward on the front of the water trough
while allowing the rear of the water trough to drop.
4. Remove the water trough from the ice machine.
Pins Located Behind Water Curtain
